S9S08AW16E5CFDE
IC MCU 8BIT 16KB FLASH 48QFNManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. S08 microcontroller, part number S9S08AW16E5CFDE, features an 8-bit S08 core operating at up to 40MHz. This device offers 16KB of FLASH program memory and 1KB of RAM. Connectivity options include I2C, SCI, and SPI interfaces. It is equipped with 38 general-purpose I/O pins and integrates an 8-channel, 10-bit Analog-to-Digital converter. Peripherals include LVD, POR, PWM, and WDT. The component is housed in a 48-VFQFN exposed pad package, suitable for surface mounting. Operating voltage is specified from 2.7V to 5.5V, with an operating temperature range of -40°C to 85°C. This microcontroller is commonly utilized in automotive, industrial, and consumer electronics applications.
Additional Information
Series: S08RoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: Not For New DesignsPackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 48-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Speed | 40MHz |
| Program Memory Size | 16KB (16K x 8) |
| RAM Size | 1K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | S08 |
| Data Converters | A/D 8x10b |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | I2C, SCI, SPI |
| Peripherals | LVD, POR, PWM, WDT |
| Supplier Device Package | 48-QFN-EP (7x7) |
| Number of I/O | 38 |
| Programmable | Not Verified |
