S912ZVLA12ACLFR
S12Z CPU, 128K FLASHManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
S12Z S12 MagniV Microcontroller IC 16-Bit 32MHz 128KB (128K x 8) FLASH 48-LQFP (7x7)
Additional Information
Series: S12 MagniVRoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 48-LQFP |
| Mounting Type | Surface Mount |
| Speed | 32MHz |
| Program Memory Size | 128KB (128K x 8) |
| RAM Size | 8K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External, Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 2K x 8 |
| Core Processor | S12Z |
| Data Converters | A/D 10x10b, 10x12b; D/A 1x8b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 5.5V ~ 18V |
| Connectivity | CANbus, SPI |
| Peripherals | LVD, POR, PWM, WDT |
| Supplier Device Package | 48-LQFP (7x7) |
| Number of I/O | 34 |
