S912XDT256F1MAA
IC MCU 16BIT 256KB FLASH 80QFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. HCS12X Series microcontroller, part number S912XDT256F1MAA, features a 16-bit HCS12X core operating at 80MHz. This component offers 256KB of FLASH program memory and 16KB of RAM, along with 4KB of EEPROM. Connectivity options include CANbus, I2C, SCI, and SPI interfaces. Integrated peripherals such as LVD, POR, PWM, and WDT enhance its functionality. The device includes 8x12-bit Analog-to-Digital converters and provides 59 I/O lines. Supplied in an 80-QFP (14x14) package for surface mounting, it operates within an ambient temperature range of -40°C to 125°C. This microcontroller is suitable for applications in automotive, industrial automation, and consumer electronics.
Additional Information
Series: HCS12XRoHS Status: ROHS3 CompliantManufacturer Lead Time: 12 week(s)Product Status: Not For New DesignsPackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 80-QFP |
| Mounting Type | Surface Mount |
| Speed | 80MHz |
| Program Memory Size | 256KB (256K x 8) |
| RAM Size | 16K x 8 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | 4K x 8 |
| Core Processor | HCS12X |
| Data Converters | A/D 8x12b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 3.15V ~ 5.5V |
| Connectivity | CANbus, I2C, SCI, SPI |
| Peripherals | LVD, POR, PWM, WDT |
| Supplier Device Package | 80-QFP (14x14) |
| Number of I/O | 59 |
| Programmable | Not Verified |
