PXAG49KBA/00,512
IC MCU 16BIT 64KB FLASH 44PLCCManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. XA series microcontroller, part number PXAG49KBA-00-512. This 16-bit microcontroller features a XA core operating at 30MHz. It offers 64KB of FLASH program memory and 2KB of RAM. The device includes UART/USART connectivity and peripherals such as PWM and WDT. With 32 I/O lines, it supports external oscillators and operates within a voltage range of 4.5V to 5.5V. The PXAG49KBA-00-512 is housed in a 44-PLCC (J-Lead) package suitable for surface mounting and operates across a temperature range of 0°C to 70°C. This component is utilized in various industrial automation and control applications.
Additional Information
Series: XARoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 44-LCC (J-Lead) |
| Mounting Type | Surface Mount |
| Speed | 30MHz |
| Program Memory Size | 64KB (64K x 8) |
| RAM Size | 2K x 8 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | XA |
| Data Converters | - |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
| Connectivity | UART/USART |
| Peripherals | PWM, WDT |
| Supplier Device Package | 44-PLCC (16.59x16.59) |
| Number of I/O | 32 |
| Programmable | Not Verified |
