P80C31SBPN,112
IC MCU 8BIT ROMLESS 40DIPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. 80C series 8051 microcontroller, part number P80C31SBPN-112, features an 8-bit core operating at 16MHz. This ROMless device offers 128 x 8 bytes of RAM and 32 general-purpose I/O pins. Connectivity includes a UART/USART interface. Peripherals include Power-On Reset (POR). The component is supplied in a 40-DIP (0.600", 15.24mm) through-hole package, suitable for industrial and consumer electronics applications. It operates within a voltage range of 2.7V to 5.5V and has an operating temperature range of 0°C to 70°C.
Additional Information
Series: 80CRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 40-DIP (0.600"", 15.24mm) |
| Mounting Type | Through Hole |
| Speed | 16MHz |
| Program Memory Size | - |
| RAM Size | 128 x 8 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | ROMless |
| EEPROM Size | - |
| Core Processor | 8051 |
| Data Converters | - |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Connectivity | UART/USART |
| Peripherals | POR |
| Supplier Device Package | 40-DIP |
| Number of I/O | 32 |
| Programmable | Not Verified |
