MPC566CZP56
IC MCU 32BIT 1MB FLASH 388PBGAManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
The NXP USA Inc. MPC5xx series microcontroller, part number MPC566CZP56, is a 32-bit single-core PowerPC device operating at 56MHz. This unit features 1MB of FLASH program memory and 36KB of RAM, with a program memory organization of 1M x 8. Connectivity options include CANbus, EBI/EMI, SCI, SPI, and UART/USART. Integrated peripherals consist of POR, PWM, and WDT. The device includes a 40x10-bit A/D data converter. Supplied in a 388-PBGA (27x27) surface mount package, it operates within a voltage range of 2.5V to 2.7V and an ambient temperature range of -40°C to 85°C. This component is suitable for applications in the automotive and industrial sectors.
Additional Information
Series: MPC5xxRoHS Status: RoHS non-compliantManufacturer Lead Time: 12 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 388-BBGA |
| Mounting Type | Surface Mount |
| Speed | 56MHz |
| Program Memory Size | 1MB (1M x 8) |
| RAM Size | 36K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | PowerPC |
| Data Converters | A/D 40x10b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 2.5V ~ 2.7V |
| Connectivity | CANbus, EBI/EMI, SCI, SPI, UART/USART |
| Peripherals | POR, PWM, WDT |
| Supplier Device Package | 388-PBGA (27x27) |
| Number of I/O | 56 |
| Programmable | Not Verified |
