MMC2107CFCAF33
IC MCU 32BIT 128KB FLASH 100LQFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. MCore Series microcontroller, part number MMC2107CFCAF33, features an M210 core with a 16/32-bit architecture operating at 33MHz. This device offers 128KB of FLASH program memory (128K x 8) and 8KB of RAM. On-chip peripherals include Power-On Reset (POR), Pulse Width Modulation (PWM), and Watchdog Timer (WDT). Data conversion capabilities are provided by an 8x10-bit Analog-to-Digital converter. Connectivity options include EBI/EMI, SCI, and SPI. The MMC2107CFCAF33 is housed in a 100-LQFP (14x14) surface mount package and operates within a voltage range of 2.7V to 3.6V. The operating temperature range is -40°C to 85°C (TA). This component is suitable for industrial automation, automotive, and consumer electronics applications.
Additional Information
Series: MCoreRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 100-LQFP |
| Mounting Type | Surface Mount |
| Speed | 33MHz |
| Program Memory Size | 128KB (128K x 8) |
| RAM Size | 8K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | M210 |
| Data Converters | A/D 8x10b |
| Core Size | 16/32-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 3.6V |
| Connectivity | EBI/EMI, SCI, SPI |
| Peripherals | POR, PWM, WDT |
| Supplier Device Package | 100-LQFP (14x14) |
| Number of I/O | 72 |
| Programmable | Not Verified |
