MKW37A512VFT4
IC MCU 32BIT 512KB FLASH 48HVQFNManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. Kinetis KW37A/Z series microcontroller, part number MKW37A512VFT4. This 32-bit single-core ARM Cortex-M0+ processor operates at 48MHz, featuring 512KB of FLASH program memory and 64KB of RAM. Connectivity options include I2C, SPI, and UART/USART interfaces. Integrated peripherals include a 16-bit SAR Analog-to-Digital converter, brown-out detect/reset, low voltage detection (LVD), power-on reset (POR), pulse-width modulation (PWM), and watchdog timer (WDT). The device is supplied in a 48-HVQFN (7x7) package with wettable flank surface mount technology. Operating temperature range is -40°C to 105°C (TA), with a supply voltage of 1.71V to 3.6V. This component is suitable for applications in the automotive and industrial sectors.
Additional Information
Series: Kinetis KW37A/ZRoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 48-VFQFN Exposed Pad |
| Mounting Type | Surface Mount, Wettable Flank |
| Speed | 48MHz |
| Program Memory Size | 512KB (512K x 8) |
| RAM Size | 64K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM® Cortex®-M0+ |
| Data Converters | A/D 16b SAR |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 1.71V ~ 3.6V |
| Connectivity | I2C, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, LVD, POR, PWM, WDT |
| Supplier Device Package | 48-HVQFN (7x7) |
| Programmable | Not Verified |
Request a Quote
