MK21FX512VMC12
IC MCU 32B 512KB FLASH 121MAPBGAManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. Kinetis K20 series microcontroller, part number MK21FX512VMC12. This 32-bit ARM Cortex-M4 core microcontroller operates at 120MHz and features 512KB of FLASH program memory and 128KB of SRAM. Connectivity options include CANbus, I2C, IrDA, SPI, UART/USART, USB, and USB OTG. The device integrates a 40-channel 16-bit Analog-to-Digital converter and dual 12-bit Digital-to-Analog converters. Peripherals include DMA, I2S, LVD, POR, PWM, and WDT. This surface mount component is housed in a 121-MAPBGA (8x8) package and operates from 1.71V to 3.6V within an ambient temperature range of -40°C to 105°C. The Kinetis K20 series is commonly utilized in industrial automation, automotive, and medical applications.
Additional Information
Series: Kinetis K20RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 121-LFBGA |
| Mounting Type | Surface Mount |
| Speed | 120MHz |
| Program Memory Size | 512KB (512K x 8) |
| RAM Size | 128K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM® Cortex®-M4 |
| Data Converters | A/D 40x16b; D/A 2x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 1.71V ~ 3.6V |
| Connectivity | CANbus, I2C, IrDA, SPI, UART/USART, USB, USB OTG |
| Peripherals | DMA, I2S, LVD, POR, PWM, WDT |
| Supplier Device Package | 121-MAPBGA (8x8) |
| Number of I/O | 64 |
| Programmable | Not Verified |
