MK21DX256VMC5
IC MCU 32B 256KB FLASH 121MAPBGAManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
The NXP USA Inc. Kinetis K20 series microcontroller, part number MK21DX256VMC5, features an ARM Cortex-M4 32-bit single-core processor operating at 50MHz. This component offers 256KB of FLASH program memory and 32KB of RAM, with an additional 4KB EEPROM. Connectivity options include I2C, IrDA, SPI, UART/USART, and USB with OTG support. On-chip peripherals include DMA, I2S, LVD, POR, PWM, and WDT. Data conversion capabilities are provided by a 20x16-bit Analog-to-Digital converter and a 1x12-bit Digital-to-Analog converter. The device is supplied in a 121-MAPBGA (8x8) package, designed for surface mounting. It operates across an industrial temperature range of -40°C to 105°C (TA) and requires a supply voltage between 1.71V and 3.6V. This microcontroller is suitable for applications in industrial automation, automotive, and consumer electronics.
Additional Information
Series: Kinetis K20RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 121-LFBGA |
| Mounting Type | Surface Mount |
| Speed | 50MHz |
| Program Memory Size | 256KB (256K x 8) |
| RAM Size | 32K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 4K x 8 |
| Core Processor | ARM® Cortex®-M4 |
| Data Converters | A/D 20x16b; D/A 1x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 1.71V ~ 3.6V |
| Connectivity | I2C, IrDA, SPI, UART/USART, USB, USB OTG |
| Peripherals | DMA, I2S, LVD, POR, PWM, WDT |
| Supplier Device Package | 121-MAPBGA (8x8) |
| Number of I/O | 64 |
| Programmable | Not Verified |
