MCF5329CVM240
IC MCU 32BIT ROMLESS 256MAPBGAManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. MCF532x series microcontroller, part number MCF5329CVM240. This 32-bit Coldfire V3 core microcontroller operates at 240MHz and features a ROMless architecture. It is supplied in a 256-MAPBGA (17x17) package and supports a voltage range of 1.4V to 3.6V. Connectivity options include CANbus, EBI/EMI, Ethernet, I2C, SPI, SSI, UART/USART, and USB with OTG support. On-chip peripherals include DMA, LCD controller, PWM, and WDT. The device offers 32K x 8 RAM and 94 I/O pins. Mounting is surface mount. This component is suitable for applications in industrial automation, automotive, and networking.
Additional Information
Series: MCF532xRoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 256-LBGA |
| Mounting Type | Surface Mount |
| Speed | 240MHz |
| Program Memory Size | - |
| RAM Size | 32K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External |
| Program Memory Type | ROMless |
| EEPROM Size | - |
| Core Processor | Coldfire V3 |
| Data Converters | - |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 1.4V ~ 3.6V |
| Connectivity | CANbus, EBI/EMI, Ethernet, I2C, SPI, SSI, UART/USART, USB, USB OTG |
| Peripherals | DMA, LCD, PWM, WDT |
| Supplier Device Package | 256-MAPBGA (17x17) |
| Number of I/O | 94 |
| Programmable | Not Verified |
