MCF5212LCVM80
IC MCU 32BIT 256KB FLSH 81MAPBGAManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. MCF521x Series microcontroller, part number MCF5212LCVM80, features a 32-bit Coldfire V2 single-core processor operating at 80MHz. This device offers 256KB of FLASH program memory and 32KB of RAM. Connectivity options include I2C, SPI, and UART/USART interfaces. Peripherals include DMA, LVD, POR, PWM, and WDT. It is equipped with 8x12-bit Analog-to-Digital converters and 56 general-purpose I/O pins. The MCF5212LCVM80 is housed in an 81-MAPBGA (10x10) package, suitable for surface mounting, and operates within an ambient temperature range of -40°C to 85°C. This component is commonly utilized in industrial automation, automotive, and consumer electronics applications.
Additional Information
Series: MCF521xRoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 81-LBGA |
| Mounting Type | Surface Mount |
| Speed | 80MHz |
| Program Memory Size | 256KB (256K x 8) |
| RAM Size | 32K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | Coldfire V2 |
| Data Converters | A/D 8x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | I2C, SPI, UART/USART |
| Peripherals | DMA, LVD, POR, PWM, WDT |
| Supplier Device Package | 81-MAPBGA (10x10) |
| Number of I/O | 56 |
| Programmable | Not Verified |
