MCF52100CVM80
IC MCU 32BIT 64KB FLASH 81MAPBGAManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. MCF521xx series microcontroller MCF52100CVM80. This 32-bit single-core Coldfire V2 processor operates at 80MHz. It features 64KB of FLASH program memory and 16KB of RAM. Peripherals include DMA, LVD, POR, PWM, and WDT. Connectivity options include I2C, SPI, and UART/USART. The device is equipped with 8x12b A/D data converters and offers 55 I/O lines. The MCF52100CVM80 is supplied in a Tray package, specifically an 81-MAPBGA (10x10) surface mount package. Operating temperature range is -40°C to 85°C. This component is suitable for applications in industrial automation, automotive, and consumer electronics.
Additional Information
Series: MCF521xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: Not For New DesignsPackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 81-LBGA |
| Mounting Type | Surface Mount |
| Speed | 80MHz |
| Program Memory Size | 64KB (64K x 8) |
| RAM Size | 16K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External, Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | Coldfire V2 |
| Data Converters | A/D 8x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | I2C, SPI, UART/USART |
| Peripherals | DMA, LVD, POR, PWM, WDT |
| Supplier Device Package | 81-MAPBGA (10x10) |
| Number of I/O | 55 |
| Programmable | Not Verified |
Request a Quote
Clients Also Buy
MCF52100CVM66
IC MCU 32BIT 64KB FLASH 81MAPBGA
MCF52110CVM66
IC MCU 32BIT 128KB FLSH 81MAPBGA
MCF52110CEP66
