MCF51QU32VFM
IC MCU 32BIT 32KB FLASH 32QFNManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. MCF51Qx Series microcontroller, part number MCF51QU32VFM. This 32-bit Coldfire V1 core microcontroller operates at 50MHz, featuring 32KB of FLASH program memory and 8KB of RAM. Connectivity options include I2C, SPI, and UART/USART interfaces. The device includes an 8-channel 12-bit Analog-to-Digital converter and a single 12-bit Digital-to-Analog converter. Peripherals such as DMA, LVD, POR, PWM, and WDT are integrated. The MCF51QU32VFM is supplied in a 32-HVQFN (5x5) package suitable for surface mounting with wettable flanks. It operates within a voltage range of 1.71V to 3.6V and an ambient temperature range of -40°C to 105°C. This component finds application in automotive, industrial, and consumer electronics sectors.
Additional Information
Series: MCF51QxRoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 32-VFQFN Exposed Pad |
| Mounting Type | Surface Mount, Wettable Flank |
| Speed | 50MHz |
| Program Memory Size | 32KB (32K x 8) |
| RAM Size | 8K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | Coldfire V1 |
| Data Converters | A/D 8x12b; D/A 1x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 1.71V ~ 3.6V |
| Connectivity | I2C, SPI, UART/USART |
| Peripherals | DMA, LVD, POR, PWM, WDT |
| Supplier Device Package | 32-HVQFN (5x5) |
| Number of I/O | 22 |
| Programmable | Not Verified |
