MC908MR16CBE
IC MCU 8BIT 16KB FLASH 56PSDIPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. HC08 series microcontroller, part number MC908MR16CBE. This 8-bit HC08 core microcontroller operates at 8MHz and features 16KB of FLASH program memory. It includes 768 bytes of RAM and a 10x10-bit analog-to-digital converter. Connectivity options are provided via SCI and SPI interfaces. On-chip peripherals include LVD, POR, and PWM. The device is housed in a 56-PSDIP package, suitable for through-hole mounting. It operates within a temperature range of -40°C to 85°C. This component is commonly utilized in industrial automation, automotive, and consumer electronics applications.
Additional Information
Series: HC08RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 56-SDIP (0.600"", 15.24mm) |
| Mounting Type | Through Hole |
| Speed | 8MHz |
| Program Memory Size | 16KB (16K x 8) |
| RAM Size | 768 x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | HC08 |
| Data Converters | A/D 10x10b |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
| Connectivity | SCI, SPI |
| Peripherals | LVD, POR, PWM |
| Supplier Device Package | 56-PSDIP |
| Number of I/O | 36 |
| Programmable | Not Verified |
