MC908AB32CFUER
IC MCU 8BIT 32KB FLASH 64QFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. HC08 series microcontroller, part number MC908AB32CFUER. This 8-bit MCU features an 8MHz HC08 core and 32KB of FLASH program memory, complemented by 1KB of RAM and 512 bytes of EEPROM. Connectivity is supported via SCI and SPI interfaces. Integrated peripherals include Power-On Reset (POR) and Pulse-Width Modulation (PWM) functionality. The device also incorporates an 8-channel, 8-bit Analog-to-Digital (A/D) converter. With 51 general-purpose I/O pins and an internal oscillator, it offers robust functionality in a 64-QFP (14x14) surface-mount package. Operating voltage ranges from 4.5V to 5.5V, with an operating temperature range of -40°C to 85°C. This component is commonly utilized in automotive, industrial automation, and consumer electronics applications. Supplied on tape and reel.
Additional Information
Series: HC08RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 64-QFP |
| Mounting Type | Surface Mount |
| Speed | 8MHz |
| Program Memory Size | 32KB (32K x 8) |
| RAM Size | 1K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 512 x 8 |
| Core Processor | HC08 |
| Data Converters | A/D 8x8b |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
| Connectivity | SCI, SPI |
| Peripherals | POR, PWM |
| Supplier Device Package | 64-QFP (14x14) |
| Number of I/O | 51 |
| Programmable | Not Verified |
