MC56F8357MPYE
IC MCU 16BIT 256KB FLASH 160LQFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
The NXP USA Inc. MC56F8357MPYE is a 16-bit microcontroller from the 56F8xxx series, featuring the 56800E core processor operating at 60MHz. This device offers 256KB (128K x 16) of FLASH program memory and 10K x 16 of RAM. Integrated peripherals include POR, PWM, a temperature sensor, and a WDT. Connectivity options encompass CANbus, EBI/EMI, SCI, and SPI. It also incorporates 16 channels of 12-bit Analog-to-Digital converters. The MC56F8357MPYE is housed in a 160-LQFP (24x24) surface-mount package, designed for operation across an industrial temperature range of -40°C to 125°C. This component is suitable for applications in automotive, industrial automation, and power control systems.
Additional Information
Series: 56F8xxxRoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 160-LQFP |
| Mounting Type | Surface Mount |
| Speed | 60MHz |
| Program Memory Size | 256KB (128K x 16) |
| RAM Size | 10K x 16 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | 56800E |
| Data Converters | A/D 16x12b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.25V ~ 3.6V |
| Connectivity | CANbus, EBI/EMI, SCI, SPI |
| Peripherals | POR, PWM, Temp Sensor, WDT |
| Supplier Device Package | 160-LQFP (24x24) |
| Number of I/O | 76 |
| Programmable | Not Verified |
