MC56F8323VFBE
IC MCU 16BIT 32KB FLASH 64LQFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
The NXP USA Inc. 56F8xxx series MC56F8323VFBE is a 16-bit microcontroller featuring the 56800E core. This device operates at 60MHz and offers 32KB of FLASH program memory (16K x 16) with 12KB of RAM. Key peripherals include CANbus, SCI, and SPI connectivity, an 8-channel 12-bit Analog-to-Digital converter, Power-on Reset (POR), Pulse Width Modulation (PWM) capabilities, a temperature sensor, and a Watchdog Timer (WDT). It supports an internal oscillator and requires a supply voltage between 2.25V and 3.6V. The MC56F8323VFBE is housed in a 64-LQFP (10x10) surface-mount package and operates within an ambient temperature range of -40°C to 105°C. This component is suitable for applications in industrial automation and motor control.
Additional Information
Series: 56F8xxxRoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 64-LQFP |
| Mounting Type | Surface Mount |
| Speed | 60MHz |
| Program Memory Size | 32KB (16K x 16) |
| RAM Size | 12K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | 56800E |
| Data Converters | A/D 8x12b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.25V ~ 3.6V |
| Connectivity | CANbus, SCI, SPI |
| Peripherals | POR, PWM, Temp Sensor, WDT |
| Supplier Device Package | 64-LQFP (10x10) |
| Number of I/O | 27 |
| Programmable | Not Verified |
