MC56F8013VFAER2
IC MCU 16BIT 16KB FLASH 32LQFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. 56F8xxx series microcontroller, part number MC56F8013VFAER2. This 16-bit microcontroller features a 56800E core operating at 32MHz. It is equipped with 16KB (8K x 16) of FLASH program memory and 2K x 16 of RAM. Peripherals include Power-On Reset (POR), Pulse Width Modulation (PWM), and a Watchdog Timer (WDT). Connectivity options consist of I2C, SCI, and SPI interfaces. The device also includes a 6-channel, 12-bit Analog-to-Digital (A/D) converter. The MC56F8013VFAER2 is housed in a 32-LQFP (7x7) package, suitable for surface mounting. It operates within a voltage range of 3V to 3.6V and an ambient temperature range of -40°C to 105°C. Applications for this component are found in automotive, industrial, and consumer electronics sectors. This device is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: 56F8xxxRoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-LQFP |
| Mounting Type | Surface Mount |
| Speed | 32MHz |
| Program Memory Size | 16KB (8K x 16) |
| RAM Size | 2K x 16 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | 56800E |
| Data Converters | A/D 6x12b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | I2C, SCI, SPI |
| Peripherals | POR, PWM, WDT |
| Supplier Device Package | 32-LQFP (7x7) |
| Number of I/O | 26 |
| Programmable | Not Verified |
