MAC7112MAG40
IC MCU EXT BUS 16CH AD 144LQFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. MAC7xxx series microcontroller, part number MAC7112MAG40, is a 32-bit single-core ARM7® processor operating at 40MHz. This device features 256KB of FLASH program memory and 16KB of RAM, complemented by 32K x 8 EEPROM. Connectivity options include CANbus, I2C, SCI, and SPI interfaces. On-chip peripherals include DMA and POR. The MAC7112MAG40 integrates a 16-channel, 8/10-bit Analog-to-Digital converter and offers 112 I/O pins. It is housed in a 144-LQFP (20x20) surface-mount package, designed for operation across an extended temperature range of -40°C to 125°C. This component is suitable for applications in automotive, industrial automation, and consumer electronics sectors.
Additional Information
Series: MAC7xxxRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 144-LQFP |
| Mounting Type | Surface Mount |
| Speed | 40MHz |
| Program Memory Size | 256KB (256K x 8) |
| RAM Size | 16K x 8 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 32K x 8 |
| Core Processor | ARM7® |
| Data Converters | A/D 16x8/10b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 2.35V ~ 5.5V |
| Connectivity | CANbus, I2C, SCI, SPI |
| Peripherals | DMA, POR |
| Supplier Device Package | 144-LQFP (20x20) |
| Number of I/O | 112 |
| Programmable | Not Verified |
