LPC4322JBD144E
IC MCU 32BIT 512KB FLASH 144LQFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. LPC43xx Series microcontroller, part number LPC4322JBD144E. This 32-bit dual-core microcontroller features ARM Cortex-M4 and Cortex-M0 processors operating at up to 204MHz. It includes 512KB of FLASH program memory and 104KB of RAM, along with 16KB of EEPROM. The device offers extensive connectivity options including CANbus, EBI/EMI, I2C, IrDA, Microwire, SD, SPI, SSI, SSP, UART/USART, and USB OTG. Peripherals include DMA, I2S, Motor Control PWM, and a WDT. This surface-mount component is housed in a 144-LQFP (20x20) package. Operating voltage is 2.2V to 3.6V with an operating temperature range of -40°C to 105°C. Applications span industrial automation, automotive systems, and consumer electronics.
Additional Information
Series: LPC43xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 144-LQFP |
| Mounting Type | Surface Mount |
| Speed | 204MHz |
| Program Memory Size | 512KB (512K x 8) |
| RAM Size | 104K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 16K x 8 |
| Core Processor | ARM® Cortex®-M4/M0 |
| Data Converters | A/D 8x10b; D/A 1x10b |
| Core Size | 32-Bit Dual-Core |
| Voltage - Supply (Vcc/Vdd) | 2.2V ~ 3.6V |
| Connectivity | CANbus, EBI/EMI, I2C, IrDA, Microwire, SD, SPI, SSI, SSP, UART/USART, USB, USB OTG |
| Peripherals | Brown-out Detect/Reset, DMA, I2S, Motor Control PWM, POR, PWM, WDT |
| Supplier Device Package | 144-LQFP (20x20) |
| Number of I/O | 83 |
| Programmable | Not Verified |
