LPC2368FBD100,551
IC MCU 16/32B 512KB FLSH 100LQFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. LPC2300 series microcontroller, part number LPC2368FBD100-551. This 16/32-bit ARM7® core microcontroller operates at 72MHz and features 512KB of FLASH program memory (512K x 8) and 58KB of RAM. It includes a 10-bit Analog-to-Digital converter with 6 inputs and a 10-bit Digital-to-Analog converter. Connectivity options include CANbus, Ethernet, I2C, Microwire, Memory Card, SPI, SSI, SSP, UART/USART, and USB. Peripherals include Brown-out Detect/Reset, DMA, I2S, POR, PWM, and WDT. The device is housed in a 100-LQFP (14x14) surface mount package and operates within a temperature range of -40°C to 85°C. This component is suitable for applications in industrial automation, automotive, and consumer electronics.
Additional Information
Series: LPC2300RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 100-LQFP |
| Mounting Type | Surface Mount |
| Speed | 72MHz |
| Program Memory Size | 512KB (512K x 8) |
| RAM Size | 58K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM7® |
| Data Converters | A/D 6x10b; D/A 1x10b |
| Core Size | 16/32-Bit |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | CANbus, Ethernet, I2C, Microwire, Memory Card, SPI, SSI, SSP, UART/USART, USB |
| Peripherals | Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT |
| Supplier Device Package | 100-LQFP (14x14) |
| Number of I/O | 70 |
| Programmable | Not Verified |
