LPC2364HBD100,551
IC MCU 16/32B 128KB FLSH 100LQFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. ARM7® LPC2300 Series microcontroller featuring a 16/32-bit ARM7TDMI-S core operating at 72MHz. This device offers 128KB of FLASH program memory and 34KB of RAM. It includes integrated peripherals such as CANbus, Ethernet, I2C, SPI, UART/USART, and USB connectivity. Data conversion capabilities include six 10-bit Analog-to-Digital converters and one 10-bit Digital-to-Analog converter. Additional peripherals include DMA, I2S, POR, PWM, and WDT. With 70 I/O pins and a wide operating temperature range of -40°C to 125°C, this 100-LQFP packaged component is suitable for demanding applications in industrial automation and automotive sectors. It operates on a 3V to 3.6V supply voltage.
Additional Information
Series: LPC2300RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 100-LQFP |
| Mounting Type | Surface Mount |
| Speed | 72MHz |
| Program Memory Size | 128KB (128K x 8) |
| RAM Size | 34K x 8 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM7® |
| Data Converters | A/D 6x10b; D/A 1x10b |
| Core Size | 16/32-Bit |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | CANbus, Ethernet, I2C, Microwire, SPI, SSI, SSP, UART/USART, USB |
| Peripherals | Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT |
| Supplier Device Package | 100-LQFP (14x14) |
| Number of I/O | 70 |
| Programmable | Not Verified |
