LPC1815JBD144E
IC MCU 32BIT 768KB FLASH 144LQFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
NXP USA Inc. LPC18xx series microcontroller, part number LPC1815JBD144E, is a 32-bit ARM Cortex-M3 core processor operating at 180MHz. This device features 768KB of FLASH program memory and 136KB of RAM. Connectivity options include CANbus, EBI/EMI, I2C, IrDA, Microwire, SD, SPI, SSI, SSP, and UART/USART. The LPC1815JBD144E also includes a 10-bit Analog-to-Digital converter with 8 channels and a 10-bit Digital-to-Analog converter with 1 channel, along with 16KB of EEPROM. Peripherals such as Brown-out Detect/Reset, DMA, I2S, Motor Control PWM, POR, PWM, and WDT are integrated. The component is supplied in a 144-LQFP (20x20) package for surface mounting and operates across a temperature range of -40°C to 105°C. This device is suitable for applications in industrial automation, automotive, and consumer electronics.
Additional Information
Series: LPC18xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 144-LQFP |
| Mounting Type | Surface Mount |
| Speed | 180MHz |
| Program Memory Size | 768KB (768K x 8) |
| RAM Size | 136K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 16K x 8 |
| Core Processor | ARM® Cortex®-M3 |
| Data Converters | A/D 8x10b; D/A 1x10b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 2.2V ~ 3.6V |
| Connectivity | CANbus, EBI/EMI, I2C, IrDA, Microwire, SD, SPI, SSI, SSP, UART/USART |
| Peripherals | Brown-out Detect/Reset, DMA, I2S, Motor Control PWM, POR, PWM, WDT |
| Supplier Device Package | 144-LQFP (20x20) |
| Number of I/O | 83 |
| Programmable | Not Verified |
