DSP56F807PY80E
IC MCU 16BIT 120KB FLASH 160LQFPManufacturer: NXP USA Inc.
Categories: Microcontrollers
Quality Control: Learn More
56800 56F8xx Microcontroller IC 16-Bit 80MHz 120KB (60K x 16) FLASH 160-LQFP (24x24)
Additional Information
Series: 56F8xxRoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 160-LQFP |
| Mounting Type | Surface Mount |
| Speed | 80MHz |
| Program Memory Size | 120KB (60K x 16) |
| RAM Size | 4K x 16 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | 56800 |
| Data Converters | A/D 16x12b |
| Core Size | 16-Bit |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Connectivity | CANbus, EBI/EMI, SCI, SPI |
| Peripherals | POR, PWM, WDT |
| Supplier Device Package | 160-LQFP (24x24) |
| Number of I/O | 32 |
| Programmable | Not Verified |
