PCA9622DR,118
IC LED DRV LIN PWM 100MA 32TSSOPManufacturer: NXP USA Inc.
Categories: LED Drivers
Quality Control: Learn More
NXP USA Inc. presents the PCA9622DR-118, a 16-output linear LED driver IC. This component offers precise PWM dimming control with an output current capability of 100mA per channel. Designed for surface mount applications, it features 16 independent output channels, each capable of driving LEDs with a voltage up to 40V. The device operates within a supply voltage range of 2.3V to 5.5V and supports a dimming frequency range from 100kHz to 1MHz. The PCA9622DR-118 is housed in a 32-TSSOP package, measuring 6.10mm in width. This robust solution is well-suited for applications requiring controlled illumination, including backlighting systems. The component is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-TSSOP (0.240"", 6.10mm Width) |
| Voltage - Output | 40V |
| Mounting Type | Surface Mount |
| Number of Outputs | 16 |
| Frequency | 100kHz ~ 1MHz |
| Type | Linear |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | Backlight |
| Current - Output / Channel | 100mA |
| Internal Switch(s) | Yes |
| Topology | - |
| Supplier Device Package | 32-TSSOP |
| Dimming | PWM |
| Voltage - Supply (Min) | 2.3V |
| Voltage - Supply (Max) | 5.5V |
