SAA7105E/V1/G,518
IC DIGITAL VIDEO ENCODER 156LBGAManufacturer: NXP USA Inc.
Categories: Encoders, Decoders, Converters
Quality Control: Learn More
NXP USA Inc. SAA7105E-V1-G-518 is a high-performance digital video encoder IC. This component, packaged in a 156-LBGA (15x15) format for surface mounting, is designed for demanding video processing applications, particularly within the television industry. It facilitates the conversion of analog video signals into digital formats suitable for transmission and display. The SAA7105E-V1-G-518 operates with both analog and digital supply voltages within a precise range of 3.15V to 3.45V. Its robust design and advanced functionality make it a critical element in systems requiring efficient and accurate video encoding. This device is supplied on tape and reel for automated manufacturing processes.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 156-LBGA |
| Mounting Type | Surface Mount |
| Type | Video Encoder |
| Voltage - Supply, Analog | 3.15V ~ 3.45V |
| Voltage - Supply, Digital | 3.15V ~ 3.45V |
| Applications | TV |
| Supplier Device Package | 156-LBGA (15x15) |
