BFU530WF
RF TRANS NPN 12V 11GHZ SOT323-3Manufacturer: NXP USA Inc.
Categories: Bipolar RF Transistors
Quality Control: Learn More
RF Transistor NPN 12V 40mA 11GHz 450mW Surface Mount SC-70
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-70, SOT-323 |
| Mounting Type | Surface Mount |
| Transistor Type | NPN |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Gain | 12.5dB |
| Power - Max | 450mW |
| Current - Collector (Ic) (Max) | 40mA |
| Voltage - Collector Emitter Breakdown (Max) | 12V |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 60 @ 10mA, 8V |
| Frequency - Transition | 11GHz |
| Noise Figure (dB Typ @ f) | 1.1dB @ 1.8GHz |
| Supplier Device Package | SC-70 |
