TDA8563Q/N2/S10,11
IC AMP CLASS B STEREO 55W 13PDBSManufacturer: NXP USA Inc.
Categories: Audio Amplifiers
Quality Control: Learn More
The NXP USA Inc. TDA8563Q-N2-S10-11 is a 2-channel stereo audio amplifier IC. This Class B amplifier is designed for high-fidelity audio reproduction, delivering up to 55W per channel into a 2-ohm load. Key features include integrated depop and mute functions, robust short-circuit and thermal protection, and a standby mode for power efficiency. The device operates from a 6V to 18V supply voltage and its operating temperature range is -40°C to 85°C. The amplifier is housed in a 13-PDBS package with through-hole mounting, making it suitable for applications in automotive audio systems and general consumer electronics requiring high-power stereo amplification.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | Depop, Mute, Short-Circuit and Thermal Protection, Standby |
| Packaging | Tube |
| Package / Case | 13-SIP Formed Leads |
| Output Type | 2-Channel (Stereo) |
| Mounting Type | Through Hole |
| Type | Class B |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 6V ~ 18V |
| Max Output Power x Channels @ Load | 55W x 2 @ 2Ohm |
| Supplier Device Package | 13-PDBS |
