TDA1519CSP/N3,118
IC AMP CLSS B MONO/STER 22W 9SMSManufacturer: NXP USA Inc.
Categories: Audio Amplifiers
Quality Control: Learn More
The NXP USA Inc. TDA1519CSP-N3-118 is a Class B audio amplifier IC designed for flexible mono or stereo configurations. This component offers up to 22W output into a 4-ohm load in mono mode or 11W into a 2-ohm load per channel in stereo mode. Key features include integrated depop, mute, and standby functions, along with robust short-circuit and thermal protection for reliable operation. The device operates from a 6V to 17.5V supply voltage and is specified for a junction temperature range of -25°C to 150°C. Housed in a 9-SMS (SOT-354-1) package, it is supplied on tape and reel. Applications for this amplifier include automotive audio systems and general-purpose sound amplification.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Depop, Mute, Short-Circuit and Thermal Protection, Standby |
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-354-1 |
| Output Type | 1-Channel (Mono) or 2-Channel (Stereo) |
| Mounting Type | Through Hole |
| Type | Class B |
| Operating Temperature | -25°C ~ 150°C (TJ) |
| Voltage - Supply | 6V ~ 17.5V |
| Max Output Power x Channels @ Load | 22W x 1 @ 4Ohm; 11W x 2 @ 2Ohm |
| Supplier Device Package | 9-SMS |
