TFF11115HN/N1,111
IC FREQUENCY GEN VSAT 24HVQFNManufacturer: NXP USA Inc.
Categories: Application Specific Clock/Timing
Quality Control: Learn More
NXP USA Inc. presents the TFF11115HN-N1-111, a clock/frequency generator IC specifically engineered for Ku band VSAT applications. This component operates with a maximum frequency of 11.8GHz, offering a single clock output. The device features a PLL with a 1:4 input-to-output ratio, facilitating precise frequency synthesis. Designed for surface mounting, it is supplied in a 24-HVQFN (4x4) package, with an exposed pad for enhanced thermal performance. The operational temperature range is -40°C to 85°C, and it requires a supply voltage between 3V and 3.6V. This electronic component is utilized in satellite communications and related high-frequency systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 24-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Output | Clock |
| Frequency - Max | 11.8GHz |
| Input | Clock |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3V ~ 3.6V |
| Main Purpose | Ku band VSAT applications |
| Ratio - Input:Output | 1:4 |
| Differential - Input:Output | Yes/No |
| Supplier Device Package | 24-HVQFN (4x4) |
| PLL | Yes |
| Number of Circuits | 1 |
| Programmable | Not Verified |
