MMA8451QT
ACCELEROMETER 2-8G I2C 16QFNManufacturer: NXP USA Inc.
Categories: Accelerometers
Quality Control: Learn More
The NXP USA Inc. MMA8451QT is a low-power, three-axis, digital accelerometer with selectable full-scale ranges of ±2g, ±4g, and ±8g. This component offers configurable bandwidths from 0.78Hz to 400Hz, enabling optimization for various motion detection applications. Its output is delivered via an I2C interface, facilitating integration into embedded systems. The MMA8451QT features adjustable bandwidth, selectable scale, and a low-power sleep mode, contributing to efficient operation. It is supplied in a 16-QFN (3x3) package suitable for surface mounting. Typical applications include industrial automation, consumer electronics, and automotive systems. The device operates within a voltage range of 1.95V to 3.6V and across an industrial temperature range of -40°C to 85°C. Sensitivity varies with the selected range, from 4096 LSB/g at ±2g to 1024 LSB/g at ±8g.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Adjustable Bandwidth, Selectable Scale, Sleep Mode |
| Packaging | Tube |
| Package / Case | 16-VFQFN |
| Output Type | I2C |
| Mounting Type | Surface Mount |
| Type | Digital |
| Axis | X, Y, Z |
| Acceleration Range | ±2g, 4g, 8g |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 1.95V ~ 3.6V |
| Bandwidth | 0.78Hz ~ 400Hz |
| Supplier Device Package | 16-QFN (3x3) |
| Sensitivity (LSB/g) | 4096 (±2g) ~ 1024 (±8g) |
| Sensitivity (mV/g) | - |
