MMA6525KW
ACCELEROMETER 105G SPI 16QFNManufacturer: NXP USA Inc.
Categories: Accelerometers
Quality Control: Learn More
NXP USA Inc.'s MMA6525KW is a digital accelerometer designed for demanding applications. This component provides ±105g acceleration measurement along the X and Y axes. Featuring selectable low-pass filtering, it offers precise signal conditioning. The device communicates via an SPI interface, ensuring efficient data transfer. Supplied in a 16-QFN (6x6) package, it is suitable for surface mounting. Operating across a temperature range of -40°C to 105°C and qualified to AEC-Q100 standards, the MMA6525KW is engineered for automotive environments. Its supply voltage range is 3.135V to 5.25V.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Selectable Low Pass Filter |
| Packaging | Tube |
| Package / Case | 16-QFN Exposed Pad |
| Output Type | SPI |
| Mounting Type | Surface Mount |
| Type | Digital |
| Axis | X, Y |
| Acceleration Range | ±105g |
| Operating Temperature | -40°C ~ 105°C |
| Voltage - Supply | 3.135V ~ 5.25V |
| Bandwidth | - |
| Supplier Device Package | 16-QFN (6x6) |
| Sensitivity (LSB/g) | 18.2 |
| Sensitivity (mV/g) | - |
| Grade | Automotive |
| Qualification | AEC-Q100 |
