LPC2921FBD100,551
LPC2900 - Arm9, 32-Bit RISC MicrManufacturer: NXP Semiconductors
Categories: Microcontrollers
Quality Control: Learn More
NXP Semiconductors LPC2900 series microcontroller, part number LPC2921FBD100-551. This 16/32-bit Arm968E-S RISC core processor operates at 125MHz, featuring 128KB of FLASH program memory and 24KB of RAM. Connectivity options include CANbus, I2C, LINbus, SPI, UART/USART, and USB interfaces. The device integrates a 16-channel 8-bit Analog-to-Digital converter and includes peripherals such as DMA, POR, PWM, and WDT. It offers 60 general-purpose I/O pins and 16KB of EEPROM. Supplied in a 100-LQFP (14x14) surface-mount package, this component operates across a voltage range of 1.71V to 3.6V and an ambient temperature range of -40°C to 85°C. This microcontroller is suitable for applications in automotive, industrial control, and consumer electronics.
Additional Information
Series: LPC2900RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 100-LQFP |
| Mounting Type | Surface Mount |
| Speed | 125MHz |
| Program Memory Size | 128KB (128K x 8) |
| RAM Size | 24K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 16K x 8 |
| Core Processor | ARM968E-S |
| Data Converters | A/D 16x8b |
| Core Size | 16/32-Bit |
| Voltage - Supply (Vcc/Vdd) | 1.71V ~ 3.6V |
| Connectivity | CANbus, I2C, LINbus, SPI, UART/USART, USB |
| Peripherals | DMA, POR, PWM, WDT |
| Supplier Device Package | 100-LQFP (14x14) |
| Number of I/O | 60 |
