S32K348GHT1VPCIR
RISC Microcontroller, 32-Bit, FLASH, CORTEX-M7 CPU, 120MHz, PDFP172Manufacturer: NXP Semiconductors
Categories: Microcontrollers
Quality Control: Learn More
The NXP Semiconductors S32K348 series microcontroller, specifically the S32K348GHT1VPCIR, is a 32-bit RISC device featuring a high-performance Cortex-M7 core operating at up to 120MHz. This component offers 8MB of FLASH program memory and 1.17MB of data RAM, complemented by 128KB of data EEPROM. Its extensive peripheral set includes 8 CAN controllers, 16 UARTs, 6 SPI interfaces, 2 I2C controllers, and 2 SAI interfaces, along with 32 DMA channels for efficient data transfer. For analog processing, it incorporates three 12-bit Analog-to-Digital Converters with 24 channels. This microcontroller is designed for demanding applications across automotive, industrial, and general embedded systems, supporting a wide operating temperature range from -40°C to 105°C. The 172-lead QFP package facilitates robust surface-mount integration.
Additional Information
Series: S32K348RoHS Status: Manufacturer Lead Time: Product Status: ActivePackaging: TRDatasheet:Download Free CAD Model:
Technical Details:
| Format | Floating Point |
| Length | 16.0000 |
| Speed | 120.00000000 |
| Width | 16.0000 |
| Connectivity | CAN(8), I2C(2), SAI(2), SPI(6), UART(16) |
| Peripherals | COMPARATOR(3), DMA(32), RTC, TIMER(6), WDT |
| A_D_Converters | 24-Ch 12-bit (3) |
| ADC_Channels | Yes |
| Address_Bus_Width | 0 |
| Bit_Size | 32 |
| Boundary_Scan | Yes |
| Clock_Frequency_Max | 40.0000000000000000 |
| CPU_Family | CORTEX-M7 |
| DAC_Channels | No |
| Data_EEPROM_Size | 131072 |
| Data_RAM_Size | 1179648 |
| DMA_Channels | Yes |
| External_Data_Bus_Width | 0 |
| Integrated_Cache | Yes |
| JESD_30_Code | S-PQFP-G172 |
| Low_Power_Mode | Yes |
| Number_of_Serial_I_Os | 16 |
| Number_of_Terminals | 172 |
| Number_of_Timers | 6 |
| On_Chip_Data_RAM_Width | 8 |
| Operating_Temperature_Max | 105.0000 |
| Operating_Temperature_Min | -40.0000 |
| Package_Body_Material | PLASTIC/EPOXY |
| Package_Code | QFP |
| Package_Equivalence_Code | QFP172,.75SQ |
| Package_Shape | Square |
| Package_Style | FlatPack |
| Program_Memory_Size | 8388608 |
| Program_Memory_Type | FLASH |
| Program_Memory_Width | 8 |
| PWM_Channels | Yes |
| Seated_Height_Max | 1.7500 |
| Supply_Voltage_Max | 5.5000 |
| Supply_Voltage_Min | 2.9700 |
| Supply_Voltage_Nom | 3.3000 |
| Surface_Mount | Yes |
| Terminal_Form | Gull Wing |
| Terminal_Pitch | 0.650 |
| Terminal_Position | Dual |
| uPs_uCs_Peripheral_ICs_Type | MICROCONTROLLER, RISC |
