N74F1763N
DRAM Controller, 1M X 1, CMOS, PDIP48Manufacturer: NXP Semiconductors
Categories: Memory Controllers
Quality Control: Learn More
NXP Semiconductors N74F1763N is a CMOS DRAM controller designed for memory management in demanding applications. This component, part of the N74F1763 series, features a 1M x 1 memory organization and a 48-pin PDIP package with through-hole terminals. It supports a 20-bit address bus and exhibits bus compatibility with the 68030 microprocessor. Operating within a temperature range of 0°C to 70°C, the device requires a supply voltage between 4.5V and 5.5V, with a nominal 5.0V. Its plastic/epoxy package construction ensures robust performance. This memory controller is suitable for use in various industrial and computing systems requiring efficient DRAM control.
Additional Information
Series: N74F1763RoHS Status: Manufacturer Lead Time: Product Status: DiscontinuedPackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Technology | CMOS |
| Address_Bus_Width | 20 |
| Boundary_Scan | No |
| Bus_Compatibility | 68030 |
| External_Data_Bus_Width | 0 |
| JESD_30_Code | R-PDIP-T48 |
| Low_Power_Mode | No |
| Memory_Organization | 1M x 1 |
| Number_of_Banks | 1 |
| Number_of_Terminals | 48 |
| Operating_Temperature_Max | 70.0000 |
| Operating_Temperature_Min | 0.0000 |
| Package_Body_Material | PLASTIC/EPOXY |
| Package_Code | DIP |
| Package_Shape | Rectangular |
| Package_Style | IN-LINE |
| Supply_Voltage_Max | 5.5000 |
| Supply_Voltage_Min | 4.5000 |
| Supply_Voltage_Nom | 5.0000 |
| Surface_Mount | No |
| Terminal_Form | THROUGH-HOLE |
| Terminal_Position | Dual |
| uPs_uCs_Peripheral_ICs_Type | MEMORY CONTROLLER, DRAM |
