935262039118
EEPROM, 256X8, Serial, CMOS, PDSO8Manufacturer: NXP Semiconductors
Categories: EEPROMs
Quality Control: Learn More
NXP Semiconductors PCF85103 is a 256 x 8 bit serial EEPROM utilizing CMOS technology. This memory component operates via the I2C serial bus, supporting synchronous communication up to a maximum clock frequency of 100 kHz. The device features a 2 Kbit memory density, organized as 256 words by 8 bits each. It is housed in a PDSO8 package with a 1.27mm terminal pitch, suitable for surface mounting. Operating temperature ranges from -40°C to +85°C, with supply voltages between 2.5V and 6.0V, commonly nominal at 3.3V. The PCF85103 is employed in various industrial applications including consumer electronics and industrial control systems. Maximum write cycle time (tWC) is 10ms.
Additional Information
Series: PCF85103RoHS Status: Manufacturer Lead Time: Product Status: DiscontinuedPackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Length | 4.9000 |
| Width | 3.9000 |
| Technology | CMOS |
| Clock_Frequency_Max | 0.10000 |
| JESD_30_Code | R-PDSO-G8 |
| Memory_Density | 2048.0000000000000000 |
| Memory_IC_Type | EEPROM |
| Memory_Organization | 256X8 |
| Memory_Width | 8 |
| Number_of_Functions | 1 |
| Number_of_Terminals | 8 |
| Number_of_Words | 256.0000000000000000 |
| Number_of_Words_Code | 256 |
| Operating_Mode | Synchronous |
| Operating_Temperature_Max | 85.0 |
| Operating_Temperature_Min | -40.0 |
| Package_Body_Material | PLASTIC/EPOXY |
| Package_Code | SOP |
| Package_Shape | Rectangular |
| Package_Style | SMALL OUTLINE |
| Parallel_Serial | Serial |
| Seated_Height_Max | 1.7500 |
| Serial_Bus_Type | I2C |
| Supply_Voltage_Max | 6.00000 |
| Supply_Voltage_Min | 2.50000 |
| Supply_Voltage_Nom | 3.3 |
| Surface_Mount | Yes |
| Terminal_Form | Gull Wing |
| Terminal_Pitch | 1.270 |
| Terminal_Position | Dual |
| Write_Cycle_Time_Max_tWC | 10.0000000000000000 |
