DSP56001ARC33
Digital Signal Processor, 24-Bit Size, 24-Ext Bit, 33MHz, CMOS, CPGA88Manufacturer: NXP Semiconductors
Categories: Digital Signal Processors
Quality Control: Learn More
NXP Semiconductors DSP56001 series digital signal processor, part number DSP56001ARC33, is a 24-bit CMOS device operating at a maximum clock frequency of 33MHz. This component features a 24-bit external data bus and a 16-bit address bus. It offers 512 words of RAM and 24-bit program memory. The DSP56001ARC33 supports low-power modes and has 2 external interrupts and 1 serial I/O port. The device is housed in an 88-pin ceramic grid array (CPGA88) package with perpendicular pins. Its operating temperature ranges from -40°C to 105°C, with a supply voltage range of 4.75V to 5.25V. This component is utilized in various applications including telecommunications, audio processing, and motor control.
Additional Information
Series: DSP56001RoHS Status: Manufacturer Lead Time: Product Status: Active-UnconfirmedPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Format | Floating Point |
| Length | 34.5440 |
| Width | 34.5440 |
| Technology | CMOS |
| Address_Bus_Width | 16 |
| Barrel_Shifter | No |
| Bit_Size | 24 |
| Boundary_Scan | No |
| Clock_Frequency_Max | 33.0000000000000000 |
| External_Data_Bus_Width | 24 |
| Integrated_Cache | No |
| Internal_Bus_Architecture | Multiple |
| JESD_30_Code | S-CPGA-P88 |
| Low_Power_Mode | Yes |
| Number_of_External_Interrupts | 2 |
| Number_of_Serial_I_Os | 1 |
| Number_of_Terminals | 88 |
| On_Chip_Data_RAM_Width | 24 |
| Operating_Temperature_Max | 105.0000 |
| Operating_Temperature_Min | -40.0000 |
| Package_Body_Material | CERAMIC, METAL-SEALED COFIRED |
| Package_Code | PGA |
| Package_Equivalence_Code | PGA88,13X13 |
| Package_Shape | Square |
| Package_Style | GRID ARRAY |
| Program_Memory_Type | MROM |
| Program_Memory_Width | 24 |
| RAM_words | 512 |
| Seated_Height_Max | 3.0480 |
| Supply_Current_Max | 115.00000000 |
| Supply_Voltage_Max | 5.2500 |
| Supply_Voltage_Min | 4.7500 |
| Supply_Voltage_Nom | 5.0000 |
| Surface_Mount | No |
| Terminal_Form | PIN/PEG |
| Terminal_Pitch | 2.540 |
| Terminal_Position | Perpendicular |
| uPs_uCs_Peripheral_ICs_Type | DIGITAL SIGNAL PROCESSOR, OTHER |
