KFJ4B01120L
MOSFET P-CH 12VManufacturer: Nuvoton Technology Corporation
Categories: Single FETs, MOSFETs
Quality Control: Learn More
P-Channel 12 V 2.6A (Ta) 370mW (Ta) Surface Mount 4-CSP (1x1)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 4-XFLGA, CSP |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | P-Channel |
| Current - Continuous Drain (Id) @ 25°C | 2.6A (Ta) |
| Rds On (Max) @ Id, Vgs | 51mOhm @ 2A, 4.5V |
| FET Feature | - |
| Power Dissipation (Max) | 370mW (Ta) |
| Vgs(th) (Max) @ Id | 1V @ 2mA |
| Supplier Device Package | 4-CSP (1x1) |
| Grade | Automotive |
| Drive Voltage (Max Rds On, Min Rds On) | 1.5V, 4.5V |
| Vgs (Max) | ±8V |
| Drain to Source Voltage (Vdss) | 12 V |
| Gate Charge (Qg) (Max) @ Vgs | 10.7 nC @ 4.5 V |
| Input Capacitance (Ciss) (Max) @ Vds | 814 pF @ 10 V |
| Qualification | AEC-Q101 |
