NUC978DK41Y
IC MPU NUC970 300MHZ 128LQFPManufacturer: Nuvoton Technology Corporation
Categories: Microprocessors
Quality Control: Learn More
The Nuvoton Technology Corporation NUC970 series NUC978DK41Y is a high-performance 32-bit microprocessor featuring an ARM926EJ-S core operating at 300MHz. This single-core, 32-bit processor is housed in a 128-LQFP (14x14) surface-mount package. It supports DDR2, LVDDR, and SDRAM memory controllers, and offers extensive peripheral connectivity including multiple UART/USART, SPI, I2C, I2S, LINbus interfaces, alongside DMA, GPIO, and eMMC/SD/SDIO support. The NUC978DK41Y includes a 10/100Mbps Ethernet port and three USB 2.0 ports, as well as a dedicated LCD controller with graphics acceleration. Security is enhanced through integrated AES, ECC, SHA, and TRNG functionalities. This component is suitable for applications requiring robust processing and connectivity in industrial automation, consumer electronics, and networking infrastructure, operating within a -40°C to 85°C temperature range.
Additional Information
Series: NUC970RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 128-LQFP |
| Mounting Type | Surface Mount |
| Speed | 300MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Core Processor | ARM926EJ-S |
| Voltage - I/O | 3.3V |
| Supplier Device Package | 128-LQFP (14x14) |
| Ethernet | 10/100Mbps (1) |
| USB | USB 2.0 (3) |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | - |
| RAM Controllers | DDR2, LVDDR, SDRAM |
| Graphics Acceleration | Yes |
| Display & Interface Controllers | LCD |
| Security Features | AES, ECC, SHA, TRNG |
| SATA | - |
| Additional Interfaces | DMA, eMMC/SD/SDIO, GPIO, I2C, I2S, LINbus, SPI, UART/USART |
