W925E625FG
IC MCU 8BIT 64KB FLASH 160QFPManufacturer: Nuvoton Technology Corporation
Categories: Microcontrollers
Quality Control: Learn More
Nuvoton Technology Corporation's W925 microcontroller, part number W925E625FG, is an 8-bit 8051 core device featuring 64KB of FLASH program memory and 4KB of RAM. This component operates at a maximum speed of 3.6MHz and offers 40 I/O pins. The W925 series microcontroller includes integrated peripherals such as LCD control, Power-On Reset (POR), and Watchdog Timer (WDT). Connectivity is supported via a serial port. Designed for surface mount applications, it is housed in a 160-QFP (28x28) package and operates within a temperature range of 0°C to 70°C. The supply voltage range is 2.2V to 6V. This microcontroller finds application in various industrial sectors, including consumer electronics and automotive systems.
Additional Information
Series: W925RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 160-BQFP |
| Mounting Type | Surface Mount |
| Speed | 3.6MHz |
| Program Memory Size | 64KB (64K x 8) |
| RAM Size | 4K x 8 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | 8051 |
| Data Converters | - |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 2.2V ~ 6V |
| Connectivity | Serial Port |
| Peripherals | LCD, POR, WDT |
| Supplier Device Package | 160-QFP (28x28) |
| Number of I/O | 40 |
| Programmable | Not Verified |
