W79L532A25DL
IC MCU 8BIT 128KB FLASH 40DIPManufacturer: Nuvoton Technology Corporation
Categories: Microcontrollers
Quality Control: Learn More
The Nuvoton Technology Corporation W79L532A25DL is an 8-bit microcontroller featuring a 8052 core operating at 25MHz. This device offers 128KB of FLASH program memory and 1.25KB of RAM. Key peripherals include Power-On Reset (POR), Pulse Width Modulation (PWM), and Watchdog Timer (WDT). Connectivity options include EBI/EMI and a serial port. With 32 general-purpose I/O pins and an internal oscillator, the W79L532A25DL is suitable for applications requiring flexible interfacing and robust control. It is housed in a 40-DIP package and operates within a temperature range of 0°C to 70°C. This component is commonly utilized in industrial automation, consumer electronics, and communication systems.
Additional Information
Series: W79RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 40-DIP |
| Mounting Type | Through Hole |
| Speed | 25MHz |
| Program Memory Size | 128KB (128K x 8) |
| RAM Size | 1.25K x 8 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | 8052 |
| Data Converters | - |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V |
| Connectivity | EBI/EMI, Serial Port |
| Peripherals | POR, PWM, WDT |
| Number of I/O | 32 |
| Programmable | Not Verified |
