NUC220SE3AN
IC MCU 32BIT 128KB FLASH 64LQFPManufacturer: Nuvoton Technology Corporation
Categories: Microcontrollers
Quality Control: Learn More
The Nuvoton Technology Corporation NuMicro™ NUC220 series microcontroller, part number NUC220SE3AN, is a 32-bit ARM® Cortex®-M0 core device operating at up to 50MHz. This microcontroller features 128KB of FLASH program memory and 16KB of RAM, along with 45 general-purpose I/O pins. Connectivity options include I2C, IrDA, SPI, UART/USART, and USB interfaces. Integrated peripherals include a 7-channel 12-bit Analog-to-Digital converter, Brown-out Detect/Reset, DMA, I2S, Low Voltage Detect, Power-On Reset, PS2, PWM, and Watchdog Timer. The NUC220SE3AN is supplied in a 64-LQFP package suitable for surface mounting and operates within an ambient temperature range of -40°C to 85°C. Its robust feature set makes it suitable for applications in industrial automation, consumer electronics, and smart home devices.
Additional Information
Series: NuMicro™ NUC220RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: Not For New DesignsPackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 64-LQFP |
| Mounting Type | Surface Mount |
| Speed | 50MHz |
| Program Memory Size | 128KB (128K x 8) |
| RAM Size | 16K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM® Cortex®-M0 |
| Data Converters | A/D 7x12b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 2.5V ~ 5.5V |
| Connectivity | I2C, IrDA, SPI, UART/USART, USB |
| Peripherals | Brown-out Detect/Reset, DMA, I2S, LVD, POR, PS2, PWM, WDT |
| Number of I/O | 45 |
| Programmable | Not Verified |
