MINI51TDE
IC MCU 32BIT 4KB FLASH 33QFNManufacturer: Nuvoton Technology Corporation
Categories: Microcontrollers
Quality Control: Learn More
Nuvoton Technology Corporation's NuMicro Mini51™ DE series microcontroller, part number MINI51TDE, is a 32-bit ARM® Cortex®-M0 core-based device operating at up to 24MHz. This microcontroller features 4KB of FLASH program memory and 2KB of RAM. It offers integrated peripherals including I2C, IrDA, SPI, and UART/USART interfaces, along with an 8-channel 10-bit Analog-to-Digital converter. Additional features include Brown-out Detect/Reset, Low Voltage Detection (LVD), Power-On Reset (POR), Pulse Width Modulation (PWM) generation, and a Watchdog Timer (WDT). The MINI51TDE is packaged in a 33-QFN (5x5) surface-mount configuration and operates over a temperature range of -40°C to 105°C. This component is suitable for applications in consumer electronics and industrial automation.
Additional Information
Series: NuMicro Mini51™ DERoHS Status: ROHS3 CompliantManufacturer Lead Time: 24 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 32-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Speed | 24MHz |
| Program Memory Size | 4KB (4K x 8) |
| RAM Size | 2K x 8 |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM® Cortex®-M0 |
| Data Converters | A/D 8x10b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 2.5V ~ 5.5V |
| Connectivity | I2C, IrDA, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, LVD, POR, PWM, WDT |
| Supplier Device Package | 33-QFN (5x5) |
| Number of I/O | 29 |
| Programmable | Not Verified |
