NTE199
TRANS NPN 50V 0.1A TO92Manufacturer: NTE Electronics, Inc
Categories: Single Bipolar Transistors
Quality Control: Learn More
Bipolar (BJT) Transistor NPN 50 V 100 mA 360 mW Through Hole TO-92
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) |
| Mounting Type | Through Hole |
| Transistor Type | NPN |
| Operating Temperature | -55°C ~ 125°C (TJ) |
| Vce Saturation (Max) @ Ib, Ic | 125mV @ 1mA, 10mA |
| Current - Collector Cutoff (Max) | 30nA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 400 @ 2mA, 5V |
| Frequency - Transition | - |
| Supplier Device Package | TO-92 |
| Current - Collector (Ic) (Max) | 100 mA |
| Voltage - Collector Emitter Breakdown (Max) | 50 V |
| Power - Max | 360 mW |
