P01-24-B-1A
INCAND PANEL INDICATOR 24VManufacturer: NKK Switches
Categories: Panel Indicators, Pilot Lights
Quality Control: Learn More
NKK Switches P01-24-B-1A is an incandescent panel indicator operating at 24V with a maximum current rating of 25mA. This component features a white, flat-top rectangular lens measuring 16.20mm x 16.00mm, designed for panel mounting. The required panel cutout dimensions are 0.66 inches by 0.74 inches (16.70mm x 18.70mm) for a rectangular aperture. This indicator is commonly utilized in industrial control panels, instrumentation, and equipment status signaling applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Current | 25mA |
| Voltage | 24V |
| Type | Incandescent |
| Millicandela Rating | - |
| Termination Style | - |
| Lens Color | White |
| Viewing Angle | - |
| Ingress Protection | - |
| Ratings | Vf (Typ), If (Max) |
| Panel Cutout Dimensions | 0.66"" x 0.74"" (16.70mm x 18.70mm) |
| Wavelength - Peak | - |
| Lens Transparency | - |
| Lamp Color | - |
| Panel Cutout Shape | Rectangle |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 16.20mm x 16.00mm |
