RP110K311D-TR
IC REG LIN 3.1V 150MA DFN0808-4Manufacturer: Nisshinbo Micro Devices Inc.
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Linear Voltage Regulator IC Positive Fixed 1 Output 150mA DFN(PL)0808-4
Additional Information
Series: RP110xRoHS Status: RoHS CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 4-XFDFN Exposed Pad |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 150mA |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 2 µA |
| Voltage - Input (Max) | 5.25V |
| Number of Regulators | 1 |
| Supplier Device Package | DFN(PL)0808-4 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 3.1V |
| Control Features | Enable |
| PSRR | - |
| Voltage Dropout (Max) | 0.35V @ 150mA |
| Protection Features | Over Current |
