NJM2885DL1-25-TE1
IC REG LINEAR 2.5V 500MA TO252-3Manufacturer: Nisshinbo Micro Devices Inc.
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
The Nisshinbo Micro Devices Inc. NJM2885DL1-25-TE1 is a positive fixed output linear voltage regulator with a 2.5V output and a 500mA maximum output current. This component features a low quiescent current of 300 µA and a low dropout voltage of 0.18V at 300mA, making it suitable for power-sensitive applications. Protection features include over current, over temperature, and short circuit protection. The device operates with an input voltage up to 14V and offers a high power supply rejection ratio (PSRR) of 75dB at 1kHz. Packaged in a TO-252-3 (DPAK) surface mount configuration and supplied on a Tape & Reel, this regulator is commonly utilized in consumer electronics and industrial control systems.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 500mA |
| Operating Temperature | -40°C ~ 85°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 300 µA |
| Voltage - Input (Max) | 14V |
| Number of Regulators | 1 |
| Supplier Device Package | TO-252-3 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 2.5V |
| Control Features | - |
| PSRR | 75dB (1kHz) |
| Voltage Dropout (Max) | 0.18V @ 300mA |
| Protection Features | Over Current, Over Temperature, Short Circuit |
