NJM12884U2-15-TE1
IC REG LINEAR 1.5V 500MA SOT89-5Manufacturer: Nisshinbo Micro Devices Inc.
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Nisshinbo Micro Devices Inc. NJM12884U2-15-TE1 is a positive fixed output linear voltage regulator with a 1.5V output voltage and a 500mA maximum output current. This device features a quiescent current of 280 µA and a low dropout voltage characteristic. Protection features include over current, over temperature, and reverse current protection. The regulator offers an enable pin and a soft-start function for controlled power-up sequences. With a typical Power Supply Rejection Ratio (PSRR) of 76dB at 1kHz, it is suitable for applications requiring stable voltage regulation. The NJM12884U2-15-TE1 is supplied in a SOT-89-5 surface-mount package and operates across a temperature range of -40°C to 125°C, making it well-suited for various industrial and consumer electronics applications.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-89-5/6 |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 500mA |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 280 µA |
| Voltage - Input (Max) | 6.5V |
| Number of Regulators | 1 |
| Supplier Device Package | SOT-89-5 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 1.5V |
| Control Features | Enable, Soft Start |
| PSRR | 76dB (1kHz) |
| Voltage Dropout (Max) | - |
| Protection Features | Over Current, Over Temperature, Reverse Current |
