RP519Z331B-E2-F
IC REG BUCK 3.3V 1A 6WLCSPManufacturer: Nisshinbo Micro Devices Inc.
Categories: DC DC Switching Regulators
Quality Control: Learn More
Nisshinbo Micro Devices Inc. RP519Z series buck switching regulator, part number RP519Z331B-E2-F, offers a fixed 3.3V output voltage and a 1A output current. This highly efficient step-down converter operates with a 6MHz switching frequency, enabling a compact solution. The RP519Z331B-E2-F features a synchronous rectifier for improved efficiency and is housed in a 6-WLCSP package, suitable for surface mount applications. It accepts input voltages ranging from 2.3V to 5.5V, making it ideal for portable electronics, battery-powered devices, and various industrial control systems where space and power efficiency are critical. The operating temperature range is -40°C to 85°C.
Additional Information
Series: RP519ZRoHS Status: RoHS CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-XFBGA, WLCSP |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Down |
| Current - Output | 1A |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 6MHz |
| Voltage - Input (Max) | 5.5V |
| Topology | Buck |
| Supplier Device Package | WLCSP-6-P8 |
| Synchronous Rectifier | Yes |
| Voltage - Output (Max) | - |
| Voltage - Input (Min) | 2.3V |
| Voltage - Output (Min/Fixed) | 3.3V |
